Prisms: A Practical Guide

Read and update one case of a sealed type without an instanceof check and a cast.

Visual representation of a prism safely extracting one variant from a sum type

What You'll Learn

  • Generate a prism for each case of a sealed interface with @GeneratePrisms
  • Match a case with getOptional, and build the sum type from a case with build
  • Compose a prism with lenses and traversals, and predict whether the result is a Prism, an Affine or a Traversal
  • Decide between a prism, an instanceof check and a pattern-matching switch

The previous guide demonstrated how a Lens gives us a powerful, composable way to work with "has-a" relationships: a field that is guaranteed to exist within a record.

But what happens when the data doesn't have a guaranteed structure? What if a value can be one of several different types? This is the domain of "is-a" relationships, or sum types, commonly modelled in Java using sealed interface or enum.

For this, we need a different kind of optic: the Prism.


The Scenario: Working with JSON-like Data

A Prism plays the part of an instanceof pattern together with the variant's constructor: getOptional matches one case of a sealed type, and build returns a value of that case as the sealed type. Unlike a pattern, it is a value that composes with other optics, and modify through it changes the value only when the case matches. Choosing an optic sets it beside the other optic types.

Consider a common scenario: modelling a JSON structure. A value can be a string, a number, a boolean, or a nested object.

The Data Model: We can represent this with a sealed interface.

import org.higherkindedj.optics.annotations.GeneratePrisms;
import org.higherkindedj.optics.annotations.GenerateLenses;
import java.util.Map;

@GeneratePrisms // Generates Prisms for each case of the sealed interface
public sealed interface JsonValue {}

@GenerateLenses // Step 3 reaches the string's value through JsonStringLenses
public record JsonString(String value) implements JsonValue {}

public record JsonNumber(double value) implements JsonValue {}
public record JsonBoolean(boolean value) implements JsonValue {}

@GenerateLenses // We can still use Lenses on the product types within the sum type
public record JsonObject(Map<String, JsonValue> fields) implements JsonValue {}

Our Goal: We need to safely access and update the value of a JsonString that is deeply nested within another JsonObject. An instanceof and casting approach would be unsafe and verbose. A Lens won't work because a JsonValue might be a JsonNumber, not the JsonObject we expect.


A Step-by-Step Walkthrough

Step 1: Generating the Prisms

Just as with lenses, we annotate our sealed interface with @GeneratePrisms. This automatically creates a companion class (e.g., JsonValuePrisms) with a Prism for each permitted subtype.

// Generated automatically:
// JsonValuePrisms.jsonString() -> Prism<JsonValue, JsonString>
// JsonValuePrisms.jsonNumber() -> Prism<JsonValue, JsonNumber>
// JsonValuePrisms.jsonBoolean() -> Prism<JsonValue, JsonBoolean>
// JsonValuePrisms.jsonObject() -> Prism<JsonValue, JsonObject>

Each method takes the camelCase form of the subtype's name, or of the constant's name on an enum. A form that would be a Java keyword or literal (true, false, null) takes a trailing underscore: @GeneratePrisms on an enum like the cast's OrderStatus would give OrderStatusPrisms.new_() for its NEW constant.

A subtype that is an inner class of a generic class

An inner class of a generic class is named under that class's arguments, since without them it is raw. Where the subtype's clause leaves them free, the prism focuses a Dot of some Outlines, which is all an instanceof can check:

class Outlines<X> {

    @GeneratePrisms
    sealed interface Outline permits Outlines.Dot {}

    final class Dot implements Outline {}
}

class ReadsADot {

    Prism<Outlines.Outline, Outlines<?>.Dot> dot = OutlinePrisms.dot();
}

Where the sealed interface is generic and the clause binds the enclosing parameter, as Pinned implements Tagged<X> does, the prism declares it: <X> Prism<Tagged<X>, Outlines<X>.Pinned>. A static nested class has no enclosing arguments, so it is named as written.

Customising the Generated Package

By default, generated classes are placed in the same package as the annotated type. You can specify a different package using the targetPackage attribute:

// Generated class will be placed in org.example.generated.optics
@GeneratePrisms(targetPackage = "org.example.generated.optics")
public sealed interface JsonValue {}

This is useful when you need to avoid name collisions or organise generated code separately.

Step 2: The Core Prism Operations

A Prism is defined by two unique, failable operations:

  • getOptional(source): Attempts to focus on the target. It returns an Optional which is non-empty only if the source matches the Prism's specific case. This is the safe alternative to an instanceof check and cast.
  • build(value): Constructs the top-level type from a part. This is the reverse operation, used to put a value of the specific case back into the sum type (e.g., taking a JsonString and returning it as a JsonValue).
    Prism<JsonValue, JsonString> jsonStringPrism = JsonValuePrisms.jsonString();

    // --- Using getOptional (the safe "cast") ---
    Optional<JsonString> result1 = jsonStringPrism.getOptional(new JsonString("hello"));
    // -> Optional[JsonString[value=hello]]

    Optional<JsonString> result2 = jsonStringPrism.getOptional(new JsonNumber(123));
    // -> Optional.empty

    // --- Using build (construct the sum type from a part) ---
    JsonValue result3 = jsonStringPrism.build(new JsonString("world"));
    // -> JsonString[value=world], typed as a JsonValue

The prism picks one case of the sealed type, and every other case passes through it untouched:

Step 3: Composing Prisms for Deep Access

The true power is composing Prisms with other optics. When a Prism meets a Lens or an Affine, the focus can be missing and nothing can build the whole from it, so the result is an Affine. Two prisms stay a Prism, and anything composed with a Traversal, on either side, is a Traversal.

Direct Composition Methods

higher-kinded-j provides direct composition methods that automatically return the correct type:

  • Lens.andThen(Prism) returns Affine
  • Prism.andThen(Lens) returns Affine
  • Prism.andThen(Prism) returns Prism
  • Affine.andThen(Affine) returns Affine

See Composition Rules for the complete reference.

// Create all the optics we need
Prism<JsonValue, JsonObject> jsonObjectPrism = JsonValuePrisms.jsonObject();
Prism<JsonValue, JsonString> jsonStringPrism = JsonValuePrisms.jsonString();
Lens<JsonObject, Map<String, JsonValue>> fieldsLens = JsonObjectLenses.fields();
Lens<JsonString, String> valueLens = JsonStringLenses.value();

// Direct composition: Prism.andThen(Lens) = Affine
Affine<JsonValue, String> jsonStringValue =
    jsonStringPrism.andThen(valueLens);

// The composed optic: safely navigate from JsonObject -> userLogin field -> name field -> string value
Traversal<JsonObject, String> userNameTraversal =
    fieldsLens                      // JsonObject -> Map<String, JsonValue>
        .andThen(Traversals.forMap("userLogin"))  // -> JsonValue (if "userLogin" key exists)
        .andThen(jsonObjectPrism)   // -> JsonObject (if it's an object)
        .andThen(fieldsLens)        // -> Map<String, JsonValue>
        .andThen(Traversals.forMap("name"))       // -> JsonValue (if "name" key exists)
        .andThen(jsonStringValue);  // -> String (if it's a string)

This composed Traversal now represents a safe, deep path that will only succeed if every step in the chain matches.


When to Use Prisms vs Other Approaches

Use Prisms When

  • Type-safe variant handling: Working with sealed interface or enum cases
  • Optional data extraction: You need to safely "try" to get a specific type
  • Composable type checking: Building reusable type-safe paths
  • Functional pattern matching: Avoiding instanceof chains
// Perfect for safe type extraction
Optional<String> errorMessage = DomainErrorPrisms.inputError()
    .andThen(InputErrorLenses.message())
    .getOptional(someError);

Use Traditional instanceof When

  • One-off type checks: Not building reusable logic
  • Imperative control flow: You need if/else branching
  • A hot loop you have measured: Production Readiness says what each call allocates
// Sometimes instanceof is clearer for simple cases
String shout(JsonValue jsonValue) {
    if (jsonValue instanceof JsonString jsonStr) {
        return jsonStr.value().toUpperCase();
    }
    return "";
}

Use Pattern Matching When

  • Exhaustive case handling: You need to handle all variants
  • Complex extraction logic: Multiple levels of pattern matching
  • Modern codebases: Using recent Java features
// Pattern matching for comprehensive handling
String describe(JsonValue jsonValue) {
    return switch (jsonValue) {
        case JsonString(var str) -> str.toUpperCase();
        case JsonNumber(var num) -> String.valueOf(num);
        case JsonBoolean(var bool) -> String.valueOf(bool);
        case JsonObject(var fields) -> "Object with " + fields.size() + " fields";
    };
}

Common Pitfalls

Don't Do This

// Unsafe: Assuming the cast will succeed
JsonString jsonStr = (JsonString) jsonValue; // Can throw ClassCastException!

// Verbose: Repeated instanceof checks
String nested(JsonValue jsonValue) {
    if (jsonValue instanceof JsonObject obj1) {
        var userValue = obj1.fields().get("userLogin");
        if (userValue instanceof JsonObject obj2) {
            var nameValue = obj2.fields().get("name");
            if (nameValue instanceof JsonString str) {
                return str.value().toUpperCase();
            }
        }
    }
    return "";
}

// Inefficient: Creating prisms repeatedly
var name1 = JsonValuePrisms.jsonString().getOptional(value1);
var name2 = JsonValuePrisms.jsonString().getOptional(value2);
var name3 = JsonValuePrisms.jsonString().getOptional(value3);

Do This Instead

// Safe: Use prism's getOptional
Optional<JsonString> maybeJsonStr = JsonValuePrisms.jsonString().getOptional(jsonValue);

// Composable: Build reusable safe paths, one step at a time
var userNamePath = JsonValuePrisms.jsonObject()
    .andThen(JsonObjectLenses.fields())
    .andThen(Traversals.forMap("userLogin"))
    .andThen(JsonValuePrisms.jsonObject());
    // ... and on through "name" to the string value

// Efficient: Reuse prisms and composed paths
var stringPrism = JsonValuePrisms.jsonString();
var name1 = stringPrism.getOptional(value1);
var name2 = stringPrism.getOptional(value2);
var name3 = stringPrism.getOptional(value3);

Real-World Example: API Response Handling

Here's a practical example of using prisms to handle different API response types safely:

@GeneratePrisms
public sealed interface GatewayResponse {}
public record SuccessResponse(String data, int statusCode) implements GatewayResponse {}
public record ErrorResponse(String message, String errorCode) implements GatewayResponse {}
public record TimeoutResponse(long timeoutMs) implements GatewayResponse {}

public class ApiHandler {
    // Reusable prisms for different response types
    private static final Prism<GatewayResponse, SuccessResponse> SUCCESS =
        GatewayResponsePrisms.successResponse();
    private static final Prism<GatewayResponse, ErrorResponse> ERROR =
        GatewayResponsePrisms.errorResponse();
    private static final Prism<GatewayResponse, TimeoutResponse> TIMEOUT =
        GatewayResponsePrisms.timeoutResponse();

    public String handleResponse(GatewayResponse response) {
        // Type-safe extraction and handling
        return SUCCESS.getOptional(response)
            .map(success -> "Success: " + success.data())
            .or(() -> ERROR.getOptional(response)
                .map(error -> "Error " + error.errorCode() + ": " + error.message()))
            .or(() -> TIMEOUT.getOptional(response)
                .map(timeout -> "Request timed out after " + timeout.timeoutMs() + "ms"))
            .orElse("Unknown response type");
    }

    // Use prisms for conditional processing
    public boolean isRetryable(GatewayResponse response) {
        return ERROR.getOptional(response)
            .map(error -> "RATE_LIMIT".equals(error.errorCode()) || "TEMPORARY".equals(error.errorCode()))
            .or(() -> TIMEOUT.getOptional(response).map(t -> true))
            .orElse(false);
    }
}

Complete, Runnable Example

This example puts it all together, showing how to use the composed Traversal to perform a safe update.


import static org.higherkindedj.hkt.instances.Witnesses.*;
import static org.higherkindedj.hkt.validated.ValidatedKindHelper.VALIDATED;

import java.util.Map;
import java.util.TreeMap;
import java.util.function.Function;
import org.higherkindedj.hkt.Applicative;
import org.higherkindedj.hkt.Kind;
import org.higherkindedj.hkt.Semigroups;
import org.higherkindedj.hkt.id.Id;
import org.higherkindedj.hkt.id.IdKindHelper;
import org.higherkindedj.hkt.instances.Instances;
import org.higherkindedj.hkt.validated.Validated;
import org.higherkindedj.hkt.validated.ValidatedKind;
import org.higherkindedj.optics.Lens;
import org.higherkindedj.optics.Prism;
import org.higherkindedj.optics.Traversal;
import org.higherkindedj.optics.annotations.GenerateLenses;
import org.higherkindedj.optics.annotations.GeneratePrisms;
import org.higherkindedj.optics.annotations.GenerateTraversals;
import org.higherkindedj.optics.util.Traversals;

/**
 * A runnable example demonstrating how to use and compose Prisms to safely access and update data
 * within nested sum types (sealed interfaces).
 */
public class PrismUsageExample {

  // 1. Define a nested data model with sum types.
  @GeneratePrisms
  public sealed interface JsonValue {}

  @GenerateLenses
  public record JsonString(String value) implements JsonValue {}

  public record JsonNumber(double value) implements JsonValue {}

  public record JsonBoolean(boolean value) implements JsonValue {}

  @GenerateLenses
  @GenerateTraversals // Generates JsonObjectTraversals.fields()
  public record JsonObject(Map<String, JsonValue> fields) implements JsonValue {}

  public static void main(String[] args) {

    // 2. Create an initial, nested JSON-like structure. TreeMap keeps the printed key order stable.
    var data =
        new JsonObject(
            new TreeMap<>(
                Map.of(
                    "user",
                    new JsonObject(
                        new TreeMap<>(
                            Map.of("name", new JsonString("Alice"), "id", new JsonNumber(123)))),
                    "status",
                    new JsonString("active"),
                    "empty_field",
                    new JsonString(""))));

    System.out.println("Original Data: " + data);
    System.out.println("------------------------------------------");

    // =======================================================================
    // SCENARIO 1: Using composed Prisms and Lenses for deep, specific updates
    // =======================================================================
    System.out.println("--- Scenario 1: Using Composed Traversal for Deep Updates ---");
    Prism<JsonValue, JsonObject> jsonObjectPrism = JsonValuePrisms.jsonObject();
    Prism<JsonValue, JsonString> jsonStringPrism = JsonValuePrisms.jsonString();
    Lens<JsonObject, Map<String, JsonValue>> fieldsLens = JsonObjectLenses.fields();
    Lens<JsonString, String> jsonStringValueLens = JsonStringLenses.value();

    // Compose the optics to create the full path from the root to the user's name.
    Traversal<JsonObject, String> userToJsonName =
        fieldsLens
            .andThen(Traversals.forMap("user"))
            .andThen(jsonObjectPrism)
            .andThen(fieldsLens)
            .andThen(Traversals.forMap("name"))
            .andThen(jsonStringPrism)
            .andThen(jsonStringValueLens);

    var updatedData =
        IdKindHelper.ID
            .narrow(
                userToJsonName.modifyF(
                    name -> Id.of(name.toUpperCase()), data, Instances.monad(id())))
            .value();

    System.out.println("After deep `modify`:    " + updatedData);
    System.out.println("------------------------------------------");

    // =======================================================================
    // SCENARIO 2: Using the generated Traversal to operate on all elements
    // =======================================================================
    System.out.println("--- Scenario 2: Using Generated Traversal to Validate All Fields ---");

    Traversal<JsonObject, String> allTopLevelStringValues =
        JsonObjectTraversals.fields() // Traverses all values in the `fields` map
            .andThen(jsonStringPrism) // Filters for strings
            .andThen(jsonStringValueLens); // Gets the string content

    Function<String, Kind<ValidatedKind.Witness<String>, String>> checkNonEmpty =
        s ->
            s.isEmpty()
                ? VALIDATED.widen(Validated.invalid("A string field was empty"))
                : VALIDATED.widen(Validated.valid(s));

    Applicative<ValidatedKind.Witness<String>> applicative =
        Instances.validated(Semigroups.string("; "));

    Kind<ValidatedKind.Witness<String>, JsonObject> validationResult =
        allTopLevelStringValues.modifyF(checkNonEmpty, data, applicative);

    System.out.println("Validation Result: " + VALIDATED.narrow(validationResult));
  }
}

Expected Output:

Original Data: JsonObject[fields={empty_field=JsonString[value=], status=JsonString[value=active], user=JsonObject[fields={id=JsonNumber[value=123.0], name=JsonString[value=Alice]}]}]
------------------------------------------
--- Scenario 1: Using Composed Traversal for Deep Updates ---
After deep `modify`:    JsonObject[fields={empty_field=JsonString[value=], status=JsonString[value=active], user=JsonObject[fields={id=JsonNumber[value=123.0], name=JsonString[value=ALICE]}]}]
------------------------------------------
--- Scenario 2: Using Generated Traversal to Validate All Fields ---
Validation Result: Invalid(A string field was empty)

Key Takeaways

  • A prism is a failable focus on one variant: getOptional is the safe cast, build the constructor back into the sum type
  • Lens handles the "what", Prism the "what if": a prism is the type-safe instanceof plus cast, composable and reusable
  • Composition tells the truth: a prism in the chain makes the result an Affine or Traversal, so the possibility of no match is visible in the type
  • Reuse beats repetition: build prisms and composed paths once and store them as constants; changes to the data model surface as compile errors at the optic, never as runtime surprises

See Also

  • Prism Toolkit: the full convenience-method catalogue and the Prisms utility factory methods for Optional, Either, Maybe, Try, and list decomposition
  • Validated Prisms: when the no needs to carry located, accumulated reasons (a validated boundary)
  • Production Readiness: what a prism costs on a miss, and when to cache a composed optic

Ready for More?

Once you're comfortable with these prism fundamentals, explore Advanced Prism Patterns for production-ready patterns including:

  • Configuration management with layered prism composition
  • API response handling with type-safe error recovery
  • Data validation pipelines and event processing systems
  • State machine implementations and plugin architectures
  • Performance optimisation and testing strategies

For Comprehension Integration

Prisms integrate with For comprehensions via the match() operation, which provides prism-based pattern matching with short-circuit semantics. When the prism match fails, the computation short-circuits using the monad's zero value (empty list, Nothing, etc.). See Optic steps in a For chain.

Hands-On Learning

Practise prism basics in Tutorial 03: Prism Basics (9 exercises).


Further Reading


Previous: Coupled Fields Next: Prism Toolkit
